Abrasion Resistance Testing of Polyaspartic

Abrasion resistance is one of the core advantages of polyaspartic, making it particularly suitable for high-frequency wear scenarios such as industrial flooring, ore chutes, and logistics warehouses.


Standard Laboratory Testing Methods

1. Taber Abrasion Test (Rotary Wear)

Standard: ASTM D4060 (U.S.)
Principle: A specified abrasive wheel (e.g., CS-10 rubber wheel, 1 kg load) is rotated against the specimen (500–5000 cycles), and the mass loss (mg) or volume loss (mm³) is measured.
Typical polyaspartic value:


Comparison: Epoxy flooring typically shows 80–150 mg loss, PVC flooring about 50–80 mg loss.

2. Falling Sand Abrasion Test (Impact Wear)

Standard: ASTM D968 (U.S.), ISO 5470 (International)
Principle: Quartz sand of specified particle size (e.g., 0.5–0.7 mm) flows through a guide tube to impact the coating surface at a 45° angle. The volume of sand required to wear through 1 μm of coating thickness (L/μm) is measured.
Polyaspartic performance: ≥40 L/μm (epoxy resin approx. 15–25 L/μm)
Note: Higher values indicate greater abrasion resistance.


Simulated Service Condition Tests

1. Steel Wheel Reciprocating Rolling (DIN Abrasion)

Standard: DIN 53754 (Germany, simulating forklift traffic)
Method: A 50 kg steel wheel repeatedly rolls across the specimen surface (1000 cycles), and the depth of wear (mm) is measured.
Polyaspartic result: <0.02 mm (ordinary concrete >0.3 mm).

2. Drop-Hammer Impact + Abrasion Combined Test

Procedure:
1.Impact the specimen with a 1 kg steel ball dropped from a height of 1 m (GB/T 1732) to create an indentation.
2.Perform Taber abrasion (500 cycles) on the indentation area.
3.Observe whether the edges of the indentation show flaking or wear propagation.
Polyaspartic advantage: Due to high elastic recovery, indentation rebound is >80%, and no crack propagation occurs in the worn area.


Extreme Environment Abrasion Tests

1. High-Temperature Abrasion Resistance (80–120°C)

Method: Preheat the specimen to the set temperature, then conduct Taber abrasion (1 kg load, 1000 cycles).
Data comparison:

2. Wet/Chemical Medium Wear Resistance

Simulation: After soaking in water for 24 h, conduct Taber abrasion; apply 5% H₂SO₄ or engine oil to the surface and perform DIN rolling tests.
Result: Wet abrasion loss increases by <10%, with no performance degradation in acid/oil environments.


Field Verification Methods

1. On-Site Friction Coefficient Test

Standard: ASTM E303 (Pendulum Skid Resistance Tester)
Purpose: Ensures a balance between abrasion resistance and slip resistance (coefficient ≥0.6 is considered safe).
Polyaspartic data: Dry: 0.75–0.85; Wet: 0.65–0.75 (with anti-slip aggregate >0.8).

2. Industrial Site Monitoring

Case indicators:

Mechanism of Abrasion Resistance

1. Molecular Structure Support

High crosslink density: Three-dimensional network structure disperses stress, reducing cutting damage from abrasive particles.
Hard-segment/soft-segment microphase separation: Hard segments (urea bonds) provide rigidity, soft segments (polyether/ester) absorb impact energy.


2. Self-Recovery Characteristics

Elastic deformation recovery: Polymer chains rebound after compression, preventing permanent deformation (contrast with the brittle fracture of epoxy resin).
Microscopic wear surface morphology: SEM images show that polyaspartic wear surfaces are smooth with no flake detachment (epoxy shows a cracked pattern).


Recommendations for Accredited Testing and Certification

1. Mandatory Tests

Taber abrasion (ASTM D4060)
Falling sand abrasion (ASTM D968)
Additional wet/high-temperature tests


2. Certification Bodies

SGS (comprehensive abrasion and slip resistance reports)
Abrasion resistance reference table (for key application scenarios):

Key Engineering Selection Criteria

1.Severe wear scenarios (ore chutes, unloading zones): Taber abrasion ≤30 mg + Falling sand ≥35 L/μm
2.Temperature resistance requirement: For environments >60°C, provide high-temperature abrasion test results (loss ≤40 mg at 80°C).
3.Impact-abrasion combination requirement: Combine drop-ball impact (GB/T 1732) with abrasion testing to ensure no loss of abrasion resistance after impact.


Core Logic Chain of Polyaspartic Abrasion Resistance


Through a three-tier validation system—standard laboratory testing (Taber/Falling sand) → simulated service condition testing (high-temperature/wet/rolling) → on-site performance monitoring—the abrasion resistance of polyaspartic can be quantitatively assured. Its molecular-level wear-resistance mechanism and elastic buffering properties far exceed those of traditional materials, making it particularly suitable for long-term protection in extreme wear conditions.
